Item

Specifications

Amplifier

Frequency Range

525~1605KHz/88~108MHz/174~237MHz

Wave Band

AM/FM/DAB BⅢ

Impendance

50Ω

Gain

AM/FM:10±2dB  DAB:20±2dB

V.S.W.R

＜2.0

Noise Figure

＜3.0

Supply Voltage

9~24V DC

Current Consumption

26~28mA

Mechanical

Cable

RG174

Fuse

500mA

PCB

FR4

Connector

Car Antenna Plug&Socket  MCX or others

Plastic Housing

ABS

Environmental

Operating Temperature

-40℃~+85℃

Relative Humidity

Up to 75%

Vibration

10 to 55Hz with 1.5mm amplitude 2hours

Environmentally Friendly

ROHS Compliant
